Marine

Leisure IPS

Volvo Penta’s IPS system offers vessels from 30-100 ft. a modern alternative to inboard shaft propulsion systems. Each is a complete package with forward facing, twin counter-rotating propellers that provide better performance, comfort and handling onboard your vessel. Volvo Penta IPS are available in double, triple or quadruple diesel installation configurations. With joystick docking and electronic vessel controls that make maneuvering both easier and safer, leisure vessel operators will have a much more enjoyable boating experience with Volvo Penta IPS.

40% Lower

PM emissions

30%

Fuel Consumption

50%

Lower Noise Levels

Longer

Cruising Range

Agile

Better Maneuverability

Model & Specifications

Model Crankshaft Power (HP) RPM Cylinders Displacement, l (in3)
IPS350 260 3500 4 4.30 (262)
IPS400 300 3500 4 4.30 (262)
IPS450 330 3500 6 5.50 (336)
IPS500 370 3500 6 5.50 (336)
IPS600 435 3500 6 5.50 (336)
IPS700 405 2900 6 7.70 (469.7)
IPS800 625 2300 6 10.84 (661.3)
IPS900 700 2350 6 10.84 (661.3)
IPS950 725 2500 6 10.84 (661.3)
IPS1050 800 2300 6 12.80 (780)
IPS1200 900 2300 6 12.80 (780)
